Y2 High-voltage Large-power Three-phase Motor, High-power electric motor,AC induction motor

1. PRODUCT INTRODUCTION OF Y2 ELECTRIC MOTOR

Y2 series high-voltage large-power three-phase asynchronous motor is totally enclosed fan-cooled,is ac motor,INDUCTION MOTOR and industrial motors, our company adopts the world advanced technology, using new materials and new process.

Y2 series of mounting dimensions and power level is in line with IEC standards.

Frame and endshields are in cast iron structure, Good heat dissipation, high rigidity, strong and durable.

For stator coil, we use insulated materials with insulation class F, the complete stator winding cores are vacuum-press-impregnated (VPI) processing, which can enable the stator windings to possess high-thermal stability and long life, the stators have high dielectric strength and mechanical strength, excellent corrosion  and moisture resistance. The rotor is made by cast-aluminum technology or copper bar welding, reliable and durable.

2. PRODUCT USE OF ELECTRIC MOTOR

Y2 series electric motor has the advantages of compact structure, beautiful appearance, high efficiency, low noise, little vibration, reliable operation, easy installation and maintenance,etc.

Y2 series electrical motor can be used to drive various kinds of general machinery, such as: Fan, water pump, compressor, crusher, cutting machine, transport machinery, etc.,

The electro-motor can be used in mine /mining, petroleum /oil, chemical, steel-iron factory, medicine, power station and other places where is worse environment.

3. TECHNICAL FEATURES OF electrical motors

1. Execution standard: IEC

2. Frame size: H315~H560

3. Rated power: 185KW~1600KW

4. Voltage: 6000V, 10000V

5. Frequency: 50Hz

6. Pole: 2P, 4P, 6P, 8P

7. Operation mode: S1 (continuous running)

8. Enclosed protect class: IP55, IP54

9. Insulation class: F

10. Cooling method: IC411

11. Mounting method: IMB3

12. Power supply conditions: voltage variable ±5%, frequency variable ±1%.

13. Ambient conditions: Altitude lower than 1000m; Ambient temperature -15~40Cº; Humidity less than 90%

4. ORDERING INSTRUCTION

When customer inquiry or order the motors, please specify the electric motor’s use, model, rated power, voltage, frequency, synchronous speed, rotation direction(view from the drive shaft end), mounting method, protection grade (IP), terminal box location.

If customers have special request, such as other power, voltage, frequency, mounting size, shaft extension size, elevation, special ambient and other, please specify.

5. CUSTOMER CAN CHOOSE

1. Can choose stator winding thermometer PTC

2. Can choose bearing thermometer Pt100

3. Can choose moistureproof heater (space heater) .
